CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores

CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores

Large Image :  CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores

Product Details:
Place of Origin: Zhejiang, China
Brand Name: Chuangfeng
Certification: ce
Contact Now
Detailed Product Description
Product Type: Paper Core Machine Processing Type: WINDING MACHINE
Voltage: 380V / 3phase / 50HZ (can Be Customized) Dimension(l*w*h): 6515*1479*1600mm
Warranty: 1 Year Production Capacity: 1-30m/min.
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Core Components: PLC, Motor Weight (KG): 4800
Product Name: Four-heads Multi-knives Paper Tube Making Machine Application: Paper Tube Core Production

CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 0
Production Description
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 2
Model
CFJG-30
Paper Layer
16 Layers
Inner Diameter
20-120mm
Wall Thickness
1-10mm
Cutting Length
Thickness 0.5-5mm: 100-1200mm
Thickness＞5mm: 200-1200mm
Winding Nose
Four-heads Double belts
Working Speed
1-30meters/min (relates to size and material quantity)
Speed Control
By Inverter
Gluing Way
Double Sides
Paper Reel Stand & Glue Unit Movement
Automatic Adjusted on Screen
Working Air Pressure
0.6Mpa
Operator
1-2 Persons
Power Supply
380V/3 Phase/50Hz
Paper Reel Stand including Paper Lifting Device
16 Layers Integral Type
Weight
4800kgs
Inner Paper Shelf
1 Set
Mandrel Shaft (mold)
2 Pieces
Belt
4 Pieces
Extra blades
5 Pieces
Useful Tool
1 Set
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 4
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 6
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 8
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 10
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 12
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 14
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 16
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 18
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 20
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 22
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 24
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 26
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 28
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 30
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 32
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 34
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 36
CE Certified Heavy Duty Paper Core Machine Automatic Paper Tube Machine for Adhesive Tape Cores 38
