Multi-Layer Eco-Friendly Paper Tube Winding Machine with PLC Control System for Textile Industry

Large Image : Multi-Layer Eco-Friendly Paper Tube Winding Machine with PLC Control System for Textile Industry

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Chuangfeng
Certification:	ce

Contact Now

Detailed Product Description

Product Type:	Paper Core Machine	Processing Type:	WINDING MACHINE
Voltage:	380V / 3phase / 50HZ (can Be Customized)	Power(w):	3KW X3
Dimension(lwh):	560022502170mm	Warranty:	1 Year
Production Capacity:	1-30m/min.	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Core Components:	PLC, Motor
Weight (KG):	1500	Product Name:	2 Heads Small Size Paper Tube Making Machine
Application:	Paper Tube Core Production	Usage:	Plastic Wrap Inner Core/Toilet Paper Inner Core/Small Paper Tube

Production Description

Model	CFJG-50
Paper Layer	3-10 Layers
Inner Diameter	20-150mm
Wall Thickness	1-5mm
Online Cutting Length	1000-5000mm
Winding Nose	Two Heads Single Belt
Working Speed	1-20 Meters/min
Speed Regulation	By Inverter
Cutting System	Single High Speed Steel Blade
Gluing Way	Double Sides
Length Fixing	By Infrared
Operator	1-2 Persons
Power Supply	380V/3 Phase/50Hz
Paper Reel Stand	10 Layers
Glue Unit	10 Layers
Inner Paper Stand	1 Set
Tube Unloading Shelf	1 Set
Mandrel Shaft	2 Pieces
Belt	2 Pieces
Extra Blades	5 Pieces
Measurement	270016001800mm
Weight	1500Kgs
