Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine

Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine
Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine

Large Image :  Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine

Product Details:
Place of Origin: Zhejiang, China
Brand Name: Chuangfeng
Certification: CE
Contact Now
Detailed Product Description
Product Type: Paper Core Machine, Paper Tube Cutting Machine Processing Type: Cutting Machine
Voltage: 380V / 3 Phase / 50Hz (customizable) Power(w): 3.0kw Wannan
Dimension(l*w*h): L4790*W2540*H1795 Warranty: 12 Months
Production Capacity: 25m/min Machinery Test Report: Provided
Video Outgoing-inspection: Provided Core Components: Motor
Weight (KG): 1400 Product Name: CFQG-SK-400 Double-Shaft Automatic Paper Core Cutting Machine
Brands Of Main Configurations: Can Be Appointed Speed: 25m/min
Power Source: 380V 3- Phase 50HZ(customizable) Model: CFQG-SK-400
After-sales Service Provided: Yes Machine For: Paper Tube Cutting
Advantage: High-quality Automation

Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine 0
Specification
Item
CFQG-SK-400 Double Shafts Paper Tube Core Cutter
Inner Diameter
50-152mm
Wall Thickness
1-20mm
Mother Tube Length
2040mm
Cutting Tube Length
5-2000mm
Cutting Blade
Single Tungsten Steel Blade
Cutting Way
Tube Rotates, knife & shafts fixed
Cutting Unit Moving Speed
25m/mn.
Cutting Tolerance
±0.15mm
Tube Fixing Way
Automatic Chuck
Tube Loading
Automatically
Tube Unloading
Automatically
Cutting Type
Pneumatic
Speed Regulation
By Inverter
Working Air Pressure
0.6Mpa
Motor
3.0kw Wannan
Inverter
Schneider
Servo Motor
Schneider
Servo Driver
Schneider
Moving Rail & Screw Rod
Shangyin
Signal Components
Omron
PLC Controller
Xinjie
Operating Panel
Touch Screen
Production Description
Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine 2
Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine 4
Factory Direct Sales Advanced Automatic Paper Tube Cutting Machine 6
